I/O ZONE 8112

OEMCtrl's I/O Zone 8112 advanced controller delivers powerful control and communications features all in a compact, economical package. Highly flexible, yet easy-to-use programming tools allow customization for a wide variety of small equipment applications enabling OEMs to achieve optimum performance and energy efficiency. Fully capable of operating in a 100% stand-alone control mode, the I/O Zone 8112 can connect to a Building Automation System (BAS) using any of today's most popular protocols, such as BACnet, Modbus, N2, and LonWorks. The I/O Zone 8112 also supports communication to OEMCtrl's line of intelligent space sensors and HMI/keypad/display units.

Small Application Controller

Whether it's heat pumps, fan coils, or small rooftop units, the I/O Zone family of controllers provides a lot of power in a small footprint. Now, even on small applications, you can have customized control sequences and with built in multi-protocol support; simplified integration into the BAS (Building Automation System), while staying competitive from a cost standpoint.

Key Features
  • I/O point count:
    • 8 digital outputs (relayed)
    • 2 analog outputs
    • 6 analog inputs
    • 5 binary inputs
  • Built-in, DIP switch selectable protocol support:
    • BACnet (ARC156 and MS/TP)
    • Modbus RTU
    • N2
    • LonWorks optional plug-in communications boards
  • Stand-alone or BAS integrated operational modes
  • On-board battery-backed real-time clock
  • Custom-programmable using our powerful Eikon graphic programming tool
  • Custom-programmable using our powerful Eikon® graphic programming tool, enabling you to create graphic logic sequences for your application
  • Built-in support for OEMCtrl's custom configurable user interfaces.
  • Built-in support for OEMCtrl's sensor Network
Accessories
  • Sensors
  • User Interfaces
  • LonWorks Option Card
Applications
  • Boilers and Burners
  • Heat Pumps
  • Roof Top Units
